Features:

• 4-Channel RAZOR Series Full Range Class D Car Amplifier
• RMS Power Rating:
  • 4 ohms: 160 watts x 4 chan.
  • 2 ohms: 250 watts x 4 chan.
  • Bridged, 4 ohms: 500 x 2 chan.
• Max power output: 2000 watts x 2 chan.
• Pulse Width Modulated MOSFET power supply
• LED power (green) and protect (red) indicators
• Variable Bass Boost (0 to +12 dB bass boost at 50 Hz)
• Soft start turn-on
• Mono channel operation
• Speaker-level (high-level) inputs
• 3-way protection circuitrh
• Heavy duty aluminum alloy heat-sink for extreme heat dissipation
• Nickel-plated RCA level inputs
• Nickel-plated screw terminals
• Variable high-pass filter (50-250 Hz, 24 dB/octave)
• Variable low-pass filter (50-250 Hz, 24 dB/octave)
• 4 gauge power and ground wiring is required for installation.
• Dimensions: 4-3/4"W x 11-1/10"L x 1-1/3"H

Specifications:

Power Specifications: Subwoofer

• RMS Power @ 4 ohms: 160 watts x 4 channels
• RMS Power @ 2 ohms: 250 watts x 4 channels
• Bridged RMS Power: 500 watts x 2 channels
• Peak Power Output: 2000 watts x 2 channels

Amplifier Specifications:

• Amplifier Class: D
• Number of Channels: 4
• Total Peak Power Output: 2000 watts
• Total RMS Power Output: 1000 watts
• Maximum Input Gauge Size: 4 AWG
• Minimum Impedance Unbridged: 2 ohms
• Minimum Impedance Bridged: 4 ohms
• THD at Rated RMS Power: 0.5%
• Speaker Level Inputs: Yes
• Preamp Outputs: No
• Built-in Crossover: LP / HP
• High-Pass Crossover Frequency: 50 - 250 Hz
• Low-Pass Crossover Frequency: 50 - 250 Hz
• Signal-to-Noise Ratio: 70 dB
• Channel Separation: 55 dB
• Bass Boost: 0 - 12 dB
• Bass/Gain Remote: No
• Fan Cooled: No
• Fuse Rating: 30A x 2
• CEA-2006 Compliant: No
