Features:

General Features:

• 500W Single 12 Inch Sealed Subwoofer Enclosure with Amplifier
• Power Handling:
• Peak: 500W
• RMS: 300W
• Final Impedance: 4 ohms
• Preloaded with single 12 Inch Subwoofers
• Included KAC Series Class A/B amplifier
• Sealed enclosure with black carpet finish
• Enclosure Dimensions: 13-3/8 Inch D x 21-15/16 Inch W x 7-5/16 Inch H

Subwoofer Features:

• Polypropylene cone
• Frequency response: 40-300 Hz
• Sensitivity: 84dB

Amplifier Features:

• Kenwood KAC-5207
• Class AB Full Range 2-Ohm Stable 2-Channel Amplifier
• RMS Power Rating:
• 4 ohms: 70 watts x 2 chan.
• 2 ohms: 85 watts x 2 chan.
• Bridged, 4 ohms: 170 watts x 1 chan.
• Max power output: 500 watts
• CTA-2006 Compliant Amplifier
• Pulse Width Modulated MOSFET power supply
• Soft start turn-on
• 2 or Mono channel operation
• Speaker-level (high-level) inputs
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Dual speaker terminals simplify the hookup of multiple speakers
• Heavy duty aluminum alloy heat-sink /li>
• Input sensitivity:
• High level: 0.2V-5V
• Frequency Response: 20 - 50,000 Hz
• Total Harmonic Distortion (THD): 1%
• Signal to Noise Ration: 100 dB
• Low-pass filter: 80 Hz, -18 dB/octave
• Fuse Rating: 25A x 1
• Dimensions: 9-1/16 InchW x 6-9/16 InchL x 2-3/16 InchH

Enclosure Features:

• Single 12 Inch Up-or-down firing sealed subwoofer enclosure
• Black carpet finish

Specifications:

Amplifier Power Specifications:

• RMS Power @ 2 ohms: 85 watts x 2 channels
• Bridged RMS Power: 170 watts x 1 channels

Amplifier Specifications:

• Amplifier Class: AB
• Number of Channels: 2
• Total Peak Power Output: 500 watts
• Total RMS Power Output: 170 watts
• Minimum Impedance Unbridged: 2 ohms
• Minimum Impedance Bridged: 4 ohms
• THD at Rated RMS Power: 1%
• Speaker Level Inputs: Yes
• Signal-to-Noise Ratio: 100 dB
• Bass/Gain Remote: No
• Fan Cooled: No
• CEA-2006 Compliant: Yes

Subwoofer Specifications:

• Number of Subs/Speakers: 1
• Subwoofer Size: 12 Inch
• Impedance (Per Voice Coil): 4 ohms
• RMS Power Handling: 500 watts
• Woofer Composition: Polypropylene
• Sensitivity: 84 dB
• Frequency Response: 40 - 300 Hz
• Recommended Enclosure Type: Sealed
