Pioneer DJ Monitor Speakers DM-40D (pair)

The DM series speakers deliver balanced, punchy bass sound and they can pump out extra power thanks to the new Class D amplifier and 4-inch woofer in each unit. Flick the switch to change from DJ mode to Production mode and the DSP settings will automatically create the best sound for each application.

Main Features

- Front-loaded 2-way bass reflex system: 4-inch fiberglass woofers produce punchy bass, even when positioned against walls, with reduced air friction.
- 3D Stereo Sound: ¾-inch (19 mm) soft dome tweeters with DECO convex diffusers deliver wide, immersive sound and a large sweet spot.
- Time Alignment: Class AB amplifiers and perfectly aligned tweeter and woofer ensure crisp, low-distortion sound and balanced frequency response.
- Smart design: Curved front edges offer rigidity and minimal resonance for clean sound at all volumes while enhancing aesthetic appeal.
- Ease of use: Front panel headphone output and volume knob, with RCA and mini jack inputs on the back for easy connection to equipment.

Specifications

Dimensions (W x H x D)

- Lch: 146 x 227 x 223 mm / 5.75” x 8.94” x 8.78”
- Rch: 146 x 227 x 212 mm / 5.75” x 8.94” x 8.35”

Weight
- Lch: 2.5 kg / 5.5 lbs.
- Rch: 2.2 kg / 4.9 lbs.

Amplifier Output
- Lch: 19 W / 4 Ω
- Rch: 19 W / 4 Ω

Impedance-                      10 kΩ

Enclosure-                         Bass reflex

Enclosure material-        MDF vinyl laminate

Power Consumption-     20 W

Power consumption during standby mode-         0.3 W or less

Terminals

Inputs

- RCA pin jack x 1 (unbalanced input)
- 5 mm stereo mini jack x 1 (unbalanced input)

Outputs

- 5 mm stereo mini jack x 1

What’s in the Box

- 2 x DM-40D Monitors

- Power cord

- Audio converter cable (3.5 mm stereo mini plug to RCA)

- Speaker cord

- Bottom cushion

- Quick Start Guide

- Precautions for Use
